McIntosh C52

McIntosh C52, Προενισχυτής, με αναλογικές και ψηφιακές εισόδους, 3 οπτικές, 2 ψηφιακές και 1 USB, υψηλής ανάλυσης αποκωδικοποίηση 24-bit/192kHz, DSD αρχεία, USB είσοδος δέχεται PCM σήματα 32-bit/384kHz και υποστηρίζει DSD64, DSD128 and DSD256 επίσης DXD 352.8kHz και DXD 384kHz, η είσοδος MCT προσφέρει ασφαλή σύνδεση για DSD αρχεία στα SACDs με το transport MCT500 SACD/CD, είσοδοι αναλογικές 2 balanced 8 unbalanced, equalizer ισοσταθμιστής τονικότητας 8 περιοχών, είσοδοι ανεξάρτητες πικάπ phono MM – MC, διαστάσεις ΠxΥxΒ 44.5×19.4×45.7 Βάρος 12,5 kg, Εγγύηση 3 έτη Αντιπροσωπείας,  Αποστολές εμπορευμάτων σε όλη την Ελλάδα, Δυνατότητα Δόσεων – Διακανονισμού,  Παρακαλούμε επικοινωνήστε στο 2103845676 για επιβεβαίωση του αποθέματος και τιμής.

McIntosh preamplifier C52,

The feature packed C52 Preamplifier lets you connect virtually any of your analog components and digital music sources – including those that play the latest high resolution formats such as DSD files – to one easy-to-use device to enjoy them all.

For connecting analog devices, it includes 3 balanced and 4 unbalanced fully assignable inputs plus 1 each of Moving Coil and Moving Magnet phono inputs for connecting a turntable and enjoying your vinyl collection. On the digital side, it has 3 optical, 2 coaxial and 1 USB input. The optical and coax inputs will decode digital music at up to 24-bit/192kHz for high resolution audio playback. The C52 is also capable of decoding and playing back DSD files for the latest in high fidelity performance; the USB input accepts PCM signals up to 32-bit/384kHz and supports DSD64, DSD128 and DSD256 plus DXD 352.8kHz and DXD 384kHz. An MCT input offers a secure, custom DSD connection for playback of the high definition audio found on SACDs when paired with the MCT500 SACD/CD Transport to deliver the purest possible sound quality from your CD library. The C52 features a 24-bit/192kHz, DSD digital-to-analog-converter (DAC).

    «Smooth? You bet. Realistic timbre? Check. Instruments and voices sound staggeringly realistic with no edge or glare whatsoever? Got it.» – Tone Audio

    «While this preamp provides a tidal wave of sound, it also shows off a good amount of detail… I keep hearing more stuff packed into the crevices of the music.» – New Record Day

New to the C52 is that all inputs are available all of the time – even if you assign certain inputs to certain devices, giving you more freedom to configure your system the way you want. The outputs have also been updated to be easier to operate when bi-amping or tri-amping so that your highs and/or lows are not inadvertently turned off. An 8 band analog equalizer allows you to fine tune your various music sources just the way you like. For headphone listening, an added dimension can be brought to your music with the addition of Headphone Crossfeed Director (HXD®). The Home Theater Pass Through feature allows for seamless integration into your multi-channel home theater system.

    This «battleship of a preamplifier» has all the connections one could want «and then some… McIntosh has taken the term “comprehensively equipped” and run with it, for maximum flexibility and future proofing… If you’re looking to indulge in your music instead of the sound it makes, then the C52 and MC301 are “strongly recommended.'» – Hi-Fi+

The C52 is one of many McIntosh products to receive Roon Tested designation from Roon Labs. It has been profiled and tested by both Roon and McIntosh for maximum compatibility. Roon will recognize it and send it audio optimized for its capabilities. No fiddling with checkboxes or dropdowns, Roon Tested devices are automatically identified and configured out of the box for a superior customer experience.

The C52’s classic black glass front panel, blue meters, knobs, illuminated logo and brushed aluminum end caps are all housed in an attractive polished stainless steel chassis that delivers a timeless look. It can be paired with a variety of amplifiers, speakers, room correction devices, CD players, turntables, tuners and other source components to make a complete home audio system. Contact your local dealer to learn more.

Τεχνικά Χαρακτηριστικά

Electronic Specifications
Number of Channels 2
Total Harmonic Distortion 0.003%
Frequency Response
+0, -0.5dB from 20Hz to 20kHz
+0, -3dB from 15Hz to 100kHz
Maximum Volts Out (Balanced / Unbalanced) 16V RMS / 8V RMS
Sensitivity High Level (Balanced / Unbalanced) 900mV / 450mV
Sensitivity Phono (Moving Coil) 0.45mV
Sensitivity Phono (Moving Magnet) 4.5mV
Signal To Noise Ratio (High Level) 100dB
Signal To Noise Ratio (Moving Coil) 80dB
Signal To Noise Ratio (Moving Magnet) 82dB
Voltage Gain (High Level) 15dB
Voltage Gain (Moving Coil) 60dB
Voltage Gain (Moving Magnet) 40dB
Input Impedance (Balanced / Unbalanced) 44K ohm, 22K ohm
Connectivity
Balanced Input 3
Unbalanced Input 4
Phono Input Moving Coil 1 (adjustable)
Phono Input Moving Magnet 1 (adjustable)
Upgradeable Digital Audio Module No
Digital Coaxial Input 2
Digital Optical Input 3
Digital MCT (DIN) Input 1
Digital USB Input 1
HDMI (ARC) Input 0
Digital AES/EBU Input 0
Balanced Fixed Output 0
Balanced Variable Output 3
Unbalanced Fixed Output 1
Unbalanced Variable Output 3
Headphone Output 1/4″ High Drive with Headphone Crossfeed Director (HXD®)
Input Level Match Yes, +/- 6dB
Home Theater PassThru Yes
Unbalanced Analog Connector Type
Premium gold-plated solid brass
Service Port 0
Control
Tone Controls 8 band
Tone Bypass and Input Assign Yes
RS232 Control Input Yes
Power Control Output 1 Main, 4 Trigger
Rear Panel Data Port 6
Rear Panel IR Sensor Input Yes
General Specifications
Multi-Chassis or Single Single, two layer
Output Meters Yes
Vacuum Tube or Solid State Solid State
Power Consumption (On) 30 Watts
Weights & Dimensions
Dimensions (W x H x D) 17.5″ (44.45cm) x 7.6″ (19.37cm) x 18″ (45.72cm)
Weight 27.5 lbs (12.5 kg) Shipping Weight 43 lbs (19.5 kg),
